A manual override switch provides added convenience. Direct 24-hour control of most loads Up to 12 ON/OFF operations each day with minimum ON/OFF times of one hour Manual override One ON and one OFF tripper included Read more. Product description Dial Timer Mechanism, Time Period 24 Hour, Contact Form Dpst, Voltage Rating 250 Volts, For Timer.

Intermatic T104 24 Hour DPST 40 Amp 208/277V Mechanical Time Switch w/ 1 Pair On/ Off Trippers Manual Override & NEMA-1 Enclosure Double-Pole Single Throw Time Clock

1. Intermatic T104-INTERMATIC - Heavy Duty Mechanical Time Switch, 40A, DPST (208-277V) - Heavy Duty Mechanical Time Switch, 40A, DPST (208-277V) The heavy duty mechanical time switch is designed for industrial, commercial and residential applications. Features a high horsepower rating that is ideal for loads up to 40 amps resistive from 120-volts and direct 24-hour time switch control of most loads.
2. How to set the time on a intermatic t101 or t103 timer. The timer trippers are reset. Timer trips are small parts that attach to the dimmer dial.
3. Intermatic T104 Electromechanical Timer, 208-277 V, 40 A, 1-23 Hr, 1-12 Cycles Per Day, Gray - Intermatic Timer - Amazon.com.

Intermatic 4004 Manual Pdf

Features Direct 24-hour control of most loads Up to 12 ON/OFF operations each day with minimum ON/OFF times of one hour Manual override One ON and one OFF tripper included Applications Indoor/Outdoor Lighting Signs Filters Electric Fences Fans Conveyors Pool Heaters Blowers Pumps Specifications Minimum ON/OFF Times: 1 hour Maximum ON/OFF Operations: 12 Input Voltages Display: 208-277 VAC, 60 Hz Operation Mode: 24-hours Has Override Switch: No Electronic Ballast: 16 A, 277 VAC, 60 Hz Motor: 2 HP, 24 FLA, 120 VAC, 60 Hz 5 HP, 28 FLA, 240 VAC, 60 Hz Maximum Power Consumption (W): 3 W Operating Temperature Max (°C): 54 Operating Temperature Max (F): 130 Operating Temperature Min (°C): -40 Operating Temperature Min (F): -40 Wire Size Max: #8 AWG Wire Size Min: #14 AWG Enclosure Type: Indoor Type 1 Metal Product Height (in): 7.875 Product Height (mm): 200 Product Width (in): 5.125 Product Width (mm): 130.2 Product Depth (in): 3.4375 Product Depth (mm): 87.3 Warranty: 1-year Downloads Documents & Downloads T100 Specifications T104 Instructions - (1) T104 Instructions - (2) 1-Year Warranty Product Rating ccsaus.png culus.png RELATED PRODUCTS:
